整機工作重量

Operating Weight

18300 kg

整機尺寸

（長×寬×高）

Overall Dimenssions

5256×4153×3130 mm

鏟dao類型

Blade type

直傾鏟 Straight-tilt

鏟dao容量

Dozing capacity

3.85 m³

鏟dao寬度

Blade width

4150 mm

鏟dao高度

Blade height

960 mm

大切削深度

Blade max.drop below ground

488 mm

鏟dao大傾斜

Blade max.tilt adjustment

730mm

爬坡性能

Grade ability

30°

發動機 Engine

發動機型號

Model

Weichai WP10G178E355

額定功率

Rated Power

131/1850 Kw/rpm

缸數-缸徑×行程

Cylinder number-bore×stroke

6-126×130mm

排量

Piston displacement

9.726L

小耗油量

Mini fule consumption

214g/kw.h

大扭矩

Max torque

830/1000-1200 N.m/rpm

冷卻方式

Cooling Type

水冷 Water

傳動系統 Power transmitting system

主離合器型式

Main clutch type

濕式，多片，慣性制動，手動操作，液壓助力

wet,multi-disc,inertia,brake,hand operate,hydraulic   booster

變速箱

Transmission

強制潤滑，手動操作

Forced lubrication, hand   operate

中央傳動

Main drive

螺旋錐齒輪，一級減速，飛濺潤滑

Spiral bevel gear, single stage   speed reduction,splash lubrication

轉向離合器

Steering clutch

濕式多片，碟簧壓緊常接合，手動液壓分離與轉向制動器聯動

Wet multi-disc,spring loaded,   hand hydraulically seperated, inter-linking with steering brake

轉向制動器

Steering brake

濕式帶式結構，腳踏制動液壓助力

Wet banding structure,   footbrake, hydraulic booster

終傳動

Final drive

直齒二級減速，飛濺潤滑式

Two-stage reduction of spur gear,splash   lubrication

行走系統 Undercarriage system

托帶輪數

Number of carrier rollers

4

支重輪數

Number of track rollers

14

履帶板寬度

Width of track shoes

1100mm

小離地間隙

Min.ground clearance

492 mm

接地比壓

Ground pressure

0.026 Mpa

履帶中心距

Track gauge

2300 mm

鏈軌節數量

Number of track shoes

44

鏈軌節距

Pitch

203.2mm

前進

Forward(km/h)

2.67/3.76/5.41/7.62/11.13 km/h

后退

Reverse(km/h)

3.48/4.9/7.05/9.92 km/h

液壓系統 Hydraulic system

高工作油壓

Max.pressure

14MPa

油泵型式

Pump type

齒輪油泵 gear pump

流量

Discharge

227L/min

工作油缸內徑×數量

Working cylinder×number

110mm×2
